High-Speed 10Gbps CWDM SFP+ Optical Transceiver - Unleash Your Network's Potential!

High-Speed 10Gbps CWDM SFP+ Optical Transceiver - Unleash Your Network's Potential!

Introducing our state-of-the-art 10Gpbs CWDM SFP+ Optical Transceiver, designed to elevate your network's performance to new heights. With its exceptional data rates of up to 11.3Gb/s and support for long-distance communication over single-mode fiber, this optical transceiver is your key to faster and more reliable data transfer.

Features:

• Up to 11.3Gb/s data links: Experience lightning-fast data transfer rates, ensuring seamless communication between devices.

• CWDM EML transmitter and PIN receiver: Benefit from advanced transmitter and receiver technology for enhanced signal performance.

• Up to 40/80/100km on 9/125µm SMF: Enjoy long-distance communication capabilities over single-mode fiber, extending your network reach.

• Hot-pluggable SFP+ footprint: Effortlessly install and replace the transceiver without disrupting network operations.

• Duplex LC/UPC type pluggable optical interface: Connect with ease using the duplex LC connector for high-speed data transmission.

• RoHS-10 compliant and lead-free: Environmentally friendly design with compliance to RoHS standards.

• Support Digital Diagnostic interface: Access real-time operating parameters for optimal performance.

• Single +3.3V power supply: Energy-efficient power supply for reduced operating costs.

• Compliant with SFF+MSA and SFF-8472: Adherence to industry standards for seamless integration.

• Metal enclosure, for lower EMI: Reduce electromagnetic interference for stable and consistent data transmissions.

• Meet ESD requirements, resist 8KV direct contact voltage: Enhanced safety and protection against electrostatic discharges.

Our 10Gpbs CWDM SFP+ Optical Transceiver is meticulously crafted to ensure top-tier performance, robustness, and compatibility. It operates at a single +3.3V power supply and complies with SFF+MSA and SFF-8472 standards, making it suitable for various networking environments. The metal enclosure provides superior EMI shielding, minimizing interference for uninterrupted data transfer.

Specification:

Our 10Gpbs CWDM SFP+ Optical Transceiver Module supports up to 10km, 40km, and 80km link lengths over single-mode fiber (SMF) via an LC duplex connector. This SFP+ transceiver is compliant with SFF-8431 and SFF-8472 MSA standards, ensuring seamless compatibility with your existing network infrastructure. Additionally, digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, providing real-time access to operating parameters.

Applications:

This easy-to-install, hot-swappable transceiver is perfect for various fiber communication applications, including 10G Ethernet and long-distance data transfer. With its exceptional features and compatibility, it caters to the diverse needs of modern networks, enhancing performance and efficiency.

Don't miss the opportunity to unleash your network's potential with our cutting-edge 10Gpbs CWDM SFP+ Optical Transceiver. Upgrade your network today and experience faster, more reliable, and long-distance data transfer for your critical business operations.
