Large Core Patch Cord for Medical Laser Power Transmission

Introduction

This fiber optical patch cable is widely used in medical laser power transmission. With 0.22 numerical aperture, the Large Core Patch Cord offered by GEZHI Photonics is a reliable and efficient solution for various applications. The company also provides customized patch cords to cater to specific requirements.

Large Core Patch Cord

Features and Benefits

The Large Core Patch Cord offers several key features that make it an excellent choice for medical and laser applications:

High Return Loss: The patch cord exhibits excellent return loss, minimizing signal reflections and ensuring reliable data transmission.
Low Insertion Loss: With low insertion loss, the patch cord effectively transfers optical signals with minimal signal degradation.
High Reliability and Stability: Designed with high-precision connectors and advanced polishing technology, the patch cord ensures consistent and stable performance over time.

Applications

The Large Core Patch Cord finds versatile applications in a range of industries:

Medical / Surgical: Its high precision and stability make it ideal for medical and surgical laser systems, ensuring accurate and reliable power transmission.
Laser Systems: The patch cord is widely used in various laser systems, providing a seamless optical connection for precise signal transmission.
Fiber Instruments: With its large core multimode fiber, the patch cord is suitable for research applications and other fiber instrument uses.

Performance Specification

Parameter	S105/125	S200/240	S272/300	S365/400	S550/600
Fiber Type
Core Diameter (um)	105	200	272	365	550
Cladding Diameter (um)	125	240	300	400	600
Coating Diameter (um)	245	270	330	440	640
Operating Wavelength (nm)	700~2200	375-2200	375-2200	375-2200	375-2200
Core NA	0.22	0.22	0.22	0.22	0.22
Connector
Operating Temperature (℃)	-40~+85	-40~+85	-40~+85	-40~+85	-40~+85
Storage Temperature (℃)	-40~+85	-40~+85	-40~+85	-40~+85	-40~+85

Customization Options

At GEZHI Photonics, we understand that each application may have unique requirements. Therefore, we offer customized patch cords, tailoring the core size and connector type to suit your specific needs. Whether it's SMA905, FC, ST, or other connectors, we have you covered.

Conclusion

In conclusion, the Large Core Patch Cord from GEZHI Photonics is an outstanding solution for medical laser power transmission and laser systems. Its high return loss, low insertion loss, and stability make it a reliable choice for critical applications. With customization options available, you can rest assured that the patch cord will meet your exact specifications. Experience the power of precision and reliability with our Large Core Patch Cord for all your fiber optic needs.
