The Magneto Optical Switch Single Stage 1X2 has been revolutionizing the fiber-optics industry. This switch, thanks to its capabilities of handling large beam cross sections and low voltage operation, not only ensures high reliability but also offers intrinsic non-reciprocity, setting it apart from other optical switches in the market.
A magneto optical switch comprises a myriad of optical components positioned meticulously along a light path. These components include a single fiber optical collimator, a first and second birefringent optic crystal, first and second half wave plate assemblies, a polarization rotation assembly, and a dual fiber optic collimator. This careful arrangement and combination result in a switch that is high-performing and remarkably efficient.
What makes the Magneto Optical Switch Single Stage 1X2 stand out are its key features:
High switching speed: The switch operates at a high speed, making it well-suited for applications that require quick data transfer and response.
Better durability: Built to withstand billions of cycles, this switch is designed for longevity, offering a robust solution to your optical switch needs.
Low voltage drive: The switch is designed to operate at low voltages, ensuring safety and efficiency during operation.
Fail-safe latching: This feature ensures the switch remains in a defined state even in the event of a system failure, thereby enhancing its reliability.
The versatility of the Magneto Optical Switch Single Stage 1X2 allows it to be employed in a range of applications:
Optical channel blocking: The switch's fast switching speed makes it ideal for blocking undesired optical channels in high-speed data transfer environments.
Configurable Add/Drop: Its ability to handle large beam cross sections and low insertion loss make it suitable for configurable Add/Drop multiplexing in optical communication systems.
System monitoring, Test & measurement: The switch's high reliability and durability make it a preferred choice in system monitoring and testing environments.
Fiber-optics sensing system: Given its low voltage operation and high switching speed, the switch is an excellent fit in fiber-optics sensing systems.
When compared to other optical switches in the market, the Magneto Optical Switch Single Stage 1X2 holds a distinct edge:
Intrinsic Non-Reciprocity: This unique feature allows the switch to control the direction of light propagation, offering more flexibility in its use.
Low Insertion Loss: The switch is designed to minimize the loss of signal power resulting from the insertion of the device in the optical path.
Reliability: With fail-safe latching and better durability, the switch has proven its reliability in various applications.
The Magneto Optical Switch Single Stage 1X2 complies with various international standards, underlining the product's commitment to quality and reliability. The exact standards complied with will depend on the specific product configuration and its application.
Let's take a look at the technical parameters that make Magneto Optical Switch Single Stage 1X2 a superior choice:
| Parameters | Unit | 1x2 |
|---|---|---|
| Wavelength Range | nm | 1520~1580 |
| Test Wavelength | nm | 1550 |
| Insertion Loss | dB | 1.0 |
| Return Loss | dB | ≥50 |
| Crosstalk | dB | ≥20 |
| PDL | dB | ≤0.2 |
| Repeatability | dB | ≤±0.01 |
| Operating Voltage | V | 2.5 |
| Durability | Cycles | ≥ 30 Billions |
| Switching Time | μs | ≤100 |
| Switching Type | n/a | Latching |
| Optical Power | mW | ≤500 |
| Operating Temperature | ℃ | –5~ +70 |
| Storage Temperature | ℃ | -40 ~ +85 |
| Relative Humidity | % | 5 ~ 95 |
| Fiber Type | n/a | G657A1 |
Correct pin configuration is critical for the efficient performance of the Magneto Optical Switch Single Stage 1X2. Here are the pin configurations for different states and optical routes:
Moreover, understanding the electric parameters is crucial to fully optimize the use of the Magneto Optical Switch Single Stage 1X2. Let's take a closer look at them:
| Type | State | Optical Route | Electric Drive | Pin 1 | Pin2 |
|---|---|---|---|---|---|
| Bidirectional | A | P1→P2 | GND | V+ | |
| B | P1→P3 | V+ | GND | ||
| Unidirectional (1X2) | A | P1→P2 | GND | V+ | |
| B | P1→P3 | V+ | GND | ||
| Unidirectional (2X1) | A | P2→P1 | V+ | GND | |
| B | P3→P1 | GND | V+ |
ParameterUnitDrive VoltageV2.5±10%Drive CurrentmA160±30%Pulse Durationμs200~400Claim FrequencyHz<800
The Magneto Optical Switch Single Stage 1X2 is primarily used in optical channel blocking, configurable add/drop, system monitoring, test & measurement, and fiber-optics sensing system. Its high switching speed, high reliability, low voltage drive, and better durability offer significant advantages over other products in the market. Its ability to operate at low voltages while handling large beam cross sections, along with low insertion loss and intrinsic non-reciprocity, make it the optimal choice for these applications.
Magneto Optical Switch Single Stage 1X2 aligns with the leading international standards for optical switches, ensuring that it delivers top-tier performance and reliability. The details of these standards will be shared soon.
Overall, the Magneto Optical Switch Single Stage 1X2 stands out as an exceptional product in the fiber-optics industry due to its advanced technical specifications, versatile pin configurations, superior electric parameters, and adherence to international standards. Whether it's for optical channel blocking, system monitoring, or fiber-optics sensing, the Magneto Optical Switch Single Stage 1X2 offers unprecedented advantages that elevate it above other products in the market.
