MEMS Optical Matrix Switch: Advanced Networking Solution

2023/7/29

MEMS Optical Matrix Switch: Enhancing Optical Networking

The MEMS MxN Optical Switch Matrix Rackmount by GEZHI is a cutting-edge optical path controlling device based on MEMS tilting mirror technology. With MxN configuration and rackmount type, it offers remote management capabilities for streamlined operation and control. The MEMS mirror platform ensures exceptional stability, making these optical switches ideal for demanding applications in the optical networking industry.

MEMS optical matrix switch

Features for Enhanced Performance

The MEMS MxN Optical Switch incorporates advanced features that set it apart from traditional switches:

SerialNet, High Reliability, High Stability: The optical switches demonstrate remarkable reliability and stability, ensuring uninterrupted network performance.
Automatic Scanning: Users can set up the channel and time interval for automatic scanning, optimizing switch functionality.
Remote Management: With RS232 Control and RJ45 Ethernet capabilities, the switch allows convenient remote management for easy configuration.
LCD Display Panel: The visual display on the LCD panel offers a user-friendly interface for efficient operation.
Transparent Transmission Signal: The switches ensure high stability and reliability for seamless signal transmission.

Applications for Enhanced Networking

The MEMS MxN Optical Switch Matrix offers versatile applications in the optical networking domain:

FITL: The switch plays a critical role in Fiber In The Loop (FITL) networks, facilitating efficient optical signal routing.
Automatic Measurement: It is useful for automatic measurement applications, enabling precise control over optical paths.
Optical Network Remote Monitoring: The switch is essential for remote monitoring and maintenance of optical networks and cables.
Cable Monitoring and Maintenance System: It contributes to effective cable monitoring and maintenance for enhanced network reliability.

Technical Index for Optimal Performance

The MEMS MxN Optical Switch ensures exceptional optical performance and reliability:

Parameters	Unit	MFSW-M×N Matrix
Operating Wavelength	nm	1260~1650 for SM, 850/1310 for MM
Insertion Loss	dB	M≤8, N≤8: ≤2.3 M≤16, N≤16: ≤2.7 M≤32, N≤32: ≤3.3 M≤64, N≤64: ≤3.7
WDL (Wavelength Dependent Loss)	dB	≤0.6
PDL (Polarization Dependent Loss)	dB	≤0.3
Return Loss	dB	SM ≥ 45, MM ≥ 30
Crosstalk	dB	SM ≥ 50, MM ≥ 30
Repeatability	dB	≤ ±0.1
Switching Time	ms	≤ 15
Durability	times	≥ 10 billion
Optical Power	mW	≤ 500
Connector	/	FC, SC, LC, ST, SMA or customized
Monitor Port	/	RJ45 & RS232 or customized
Working Power Supply (Plug type)	V	AC: 220V (50/60Hz) or DC: 36V~72V
Operating Temperature	°C	-10 ~ +60
Storage Temperature	°C	-40 ~ +85

GEZHI's MEMS optical matrix switch is a testament to cutting-edge technology, offering enhanced optical networking capabilities and remote management features. Whether in telecommunications, aerospace, or other critical applications, this switch guarantees exceptional durability, repeatability, and optical performance.

With a variety of configurations available, from 4x4 to 256x256 matrix sizes, the MEMS MxN optical switch meets the diverse needs of the optical communication industry. Its seamless integration and bidirectional functionality make it a versatile choice for MxN or NxM orientations.

Whether it's for Fiber In The Loop networks, automatic measurement, or optical network remote monitoring, GEZHI's MEMS MxN Optical Switch Matrix Rackmount is the ultimate solution. Its compact structure, fast switching time, and low insertion loss ensure optimal network performance.

For unmatched optical performance and reliability, look no further than GEZHI's MEMS MxN Optical Switch Matrix. Experience the power of advanced MEMS technology to enhance your optical networking infrastructure.

For more information or customized solutions, please contact GEZHI at sales@gezhi.net.
