The PLC Splitter Bare Fiber, based on advanced planar lightwave circuit (PLC) technology, offers a cost-effective power distribution solution with high reliability. Featuring a compact design and exceptional channel-to-channel uniformity, this optical power management device is widely used in PON networks, FTTX systems, and CATV links to efficiently split optical signals. Gezhi Photonics provides a comprehensive series of 1xN and 2xN splitters tailored for specific applications, ensuring wide operating wavelength range and superior performance.
With Gezhi Photonics' PLC Splitter Bare Fiber, optical signal power splitting becomes seamless and efficient. The device boasts the following key features:
Low Insertion Loss: Experience minimal signal attenuation, ensuring efficient power distribution in optical networks.
Low Polarization Dependent Loss (PDL): Enjoy consistent signal splitting performance across polarizations.
Compact Design: The small form factor allows easy integration into optical systems, saving valuable space.
Wide Operating Wavelength: Covering the range from 1260nm to 1650nm, ensuring compatibility with diverse optical systems.
Wide Operating Temperature: Reliable performance even in extreme temperature conditions (-40℃ to 85℃).
High Reliability and Stability: Rugged construction guarantees consistent performance over time.
The PLC Splitter Bare Fiber finds versatile applications in the following areas:
FTTX Systems: Enhance optical signal distribution and management in fiber-to-the-x systems.
PON Networks: Enable efficient optical power splitting for passive optical networks.
CATV Links: Optimize optical signal distribution in cable television networks.
Optical Signal Distribution: Realize seamless and precise optical signal splitting for various applications.
Gezhi Photonics ensures strict compliance with industry standards, meeting Telcordia GR-1209-CORE-2001, Telcordia GR-1221-CORE-1999, and RoHS requirements, guaranteeing high-quality and reliable products for your optical systems.
Gezhi Photonics offers a whole series of 1xN and 2xN splitter products, tailor-made to suit specific application needs. Whether you require customized fiber lengths, connector types, or specific package sizes, our team of experts is ready to provide personalized recommendations and configurations.
Unleash the potential of your optical networks with Gezhi Photonics' PLC Splitter Bare Fiber. Experience high-performance optical power splitting, enabling seamless and efficient optical communication.
For inquiries, consultation, or technical support, please reach out to our team at info@gezhi.com. Let us help you elevate the efficiency and performance of your optical systems with cutting-edge PLC Splitter Bare Fiber.
Gezhi Photonics offers a range of 1xN PLC Splitters with varying specifications:
| Parameter | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 |
|---|---|---|---|---|---|---|
| Operating Wavelength (nm) | 1260 ~ 1650 | 1260 ~ 1650 | 1260 ~ 1650 | 1260 ~ 1650 | 1260 ~ 1650 | 1260 ~ 1650 |
| Insertion Loss (dB) | Typical: 3.6 Max: 3.8 | Typical: 6.8 Max: 7.1 | Typical: 10.0 Max: 10.3 | Typical: 13.0 Max: 13.5 | Typical: 16.0 Max: 16.5 | Typical: 19.5 Max: 20.5 |
| Uniformity (dB) | Typical: 0.4 Max: 0.6 | Typical: 0.5 Max: 0.6 | Typical: 0.5 Max: 0.8 | Typical: 1.0 Max: 1.2 | Typical: 1.0 Max: 1.5 | Typical: 2.5 Max: 2.5 |
| PDL (dB) Max | Typical: 0.1 Max: 0.15 | Typical: 0.1 Max: 0.15 | Typical: 0.1 Max: 0.25 | Typical: 0.2 Max: 0.3 | Typical: 0.2 Max: 0.3 | Typical: 0.2 Max: 0.3 |
| Wavelength Department Loss (dB) Typical | 0.1 | 0.1 | 0.1 | 0.3 | 0.4 | 0.7 |
| Wavelength Department Loss (dB) Max | 0.2 | 0.3 | 0.4 | 0.6 | 0.8 | 1.0 |
| Temperature Department Loss Typical | 0.3 | 0.3 | 0.3 | 0.4 | 0.4 | 0.4 |
| Temperature Department Loss Max | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| Directivity (dB) Min | 55 | 55 | 55 | 55 | 55 | 55 |
| Return Loss (dB) Min | 55(50) | 55(50) | 55(50) | 55(50) | 55(50) | 55(50) |
| Operating Temperature (°C) | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 |
| Storage Temperature (°C) | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 | -40 ~ +85 |
Gezhi Photonics offers multiple package options for the PLC Splitter Bare Fiber:
| Package Type | Dimensions (mm) |
|---|---|
| PLC Splitter Bare Fiber | 4x4x40, 4x4x40, 4x4x40, 4x7x50, 4x7x50, 4x12x60 |
| PLC Splitter Blockless | 4x4x40, 4x7x60, 4x7x60, 4x12x60, 6x20x80, 6x40x100 |
| PLC Splitter Module | 100x80x10, 100x80x10, 100x80x10, 120x80x18, 120x80x18, 141x115x18 |
| PLC Splitter Rack Mountable | 19’1U 2U Rack-Mount Box, LGX Box, ODF Box |
Each package type caters to specific installation requirements and provides ease of integration into existing optical systems.
With Gezhi Photonics' PLC Splitter Bare Fiber, experience high-performance optical power management with low insertion loss and exceptional channel-to-channel uniformity. Whether it's FTTX systems, PON networks, or CATV links, this compact and reliable device is designed to elevate your optical communication.
Contact our team at info@gezhi.com for expert consultation and support. Let Gezhi Photonics be your trusted partner for cutting-edge optical solutions and exceptional performance in your optical networks.
