High-Performance PM Fused WDM Multiplexer

PM Fused WDM 488~840nm

GEZHI offers PM FBT WDM (Polarization Maintaining Fiber Fused Biconical Taper Wavelength Division Multiplexers) in the range of 488nm to 840nm, with high extinction ratio loss and low insertion loss.

Polarization Maintaining Fused WDM

• (488/532, 488/633, 532/633, 532/780, 633/780, 633/840nm)

GEZHI Photonics' fused polarization maintaining (PM) wavelength division multiplexer (WDM) can multiplex two wavelengths in a polarization maintaining fiber while maintaining the polarization of the incident light. They are bidirectional; Two discrete wavelengths entering the same port can be divided into two separate optical fiber outputs. They are not suitable for separating the output light from broadband light sources. PM WDM is commonly used in pump/signal applications that integrate erbium or ytterbium doped fiber amplifiers. They can be customized for various applications to accelerate the design cycle and implementation of new projects.

Existing Wavelengths

• 488/532nm PM WDM

• 488/633nm PM WDM

• 532/633nm PM WDM

• 532/780nm PM WDM

• 633/780nm PM WDM

• 633/840nm PM WDM

• 980/1030nm PM WDM

• 980/1064nm PM WDM

• 980/1310nm PM WDM

• 980/1550nm PM WDM

• 1064/1550nm PM WDM

• 1310/1550nm PM WDM

• 980/2000nm PM

• 1570/2000nm Polarization maintaining PM Fused WDM

GEZHI Photonics also can produce customized PM FBT WDM, welcome to contact us!

Features

• Low Insertion Loss

• High Return Loss

• High Extinction Ratio

Applications

• Optical Fiber Amplifier

• Optical Fiber Laser

• Fiber Instrument

Solutions and Product Efficacy

Our PM Fused WDM solutions are designed to provide efficient and reliable wavelength multiplexing in optical fiber systems. The low insertion loss and high extinction ratio ensure optimal performance in various applications, such as:

• Optimizing signal amplification in optical fiber amplifiers

• Enabling precise wavelength filtering in optical fiber lasers

• Facilitating signal transmission in fiber instruments

Product Comparison

Compared to traditional WDMs, our PM Fused WDM offers the following advantages:

• Higher Extinction Ratio: Ensures better signal isolation and signal-to-noise ratio.

• Lower Insertion Loss: Minimizes signal power loss, maximizing system performance.

• Polarization Maintaining: Preserves polarization state for applications requiring polarization-sensitive devices.

Case Study

One of our clients, a leading fiber optic communication company, integrated our PM Fused WDM in their optical fiber amplifier system to enhance signal amplification efficiency. The results showed a significant improvement in signal quality and overall system performance.

Custom Solutions

At GEZHI Photonics, we understand that each application has unique requirements. We offer customized PM Fused WDM solutions tailored to meet specific wavelength, channel, and power handling needs. Our team of experts is ready to assist you in finding the perfect solution for your project.

Contact Us

If you have any questions or need further information about our PM Fused WDM products, feel free to contact our sales team. We look forward to helping you achieve success in your optical fiber projects.
