GEZHI's 1x4T Optical Switches are designed with high reliability and quality, based on advanced Opto-mechanical technology. These switches are the perfect choice for optical multiplexers, cross-connect, and network switching applications that require fault and protection features.
| Performance | 1x4 T Type Switch |
|---|---|
| Operation Wavelength | 850nm or 1310/1490/1550nm |
| Insertion Loss 1 | <0.8 dB |
| Wavelength Dependent Loss | <0.2 dB |
| Polarization Dependent Loss | <0.2 dB |
| Return Loss | SM: >55 dB MM: >40 dB |
| Cross Talk | SM: >55 dB MM: >40 dB |
| Switching Time | Typical: 4 ms Max: 10 ms |
| Repeatability | <±0.02 dB |
| Durability | >10 Million Cycles |
| Switching Type | Latching / Non-Latching |
| Optical Power Handling | <500mW |
| Operating Voltage | 3V or 5V |
| Operating Temperature | -5°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Fiber Type | SM/MM Fiber |
Low Insertion Loss: With insertion loss of less than 0.8 dB, the switch ensures minimal signal attenuation, maintaining excellent signal integrity.
Low Optical Distortions: The switch's low optical distortions guarantee clean and clear transmission of optical signals without signal degradation.
High Reliability: GEZHI's 1x4T Optical Switches are designed for high reliability, suitable for critical applications that require stable performance.
Epoxy-Free Optical Path: The switches feature an epoxy-free optical path, minimizing signal loss and maximizing optical efficiency.
Integrated Electrical Position Sensor: The switches come with an integrated electrical position sensor for precise control and feedback, improving operational accuracy.
The 1x4T Optical Switch offers various applications:
Channel Blocking: The switch efficiently blocks optical channels in complex optical networks, allowing for controlled signal flow.
System Monitoring: With seamless switching capabilities, the switch aids in monitoring and managing optical systems effectively.
Configurable Add/Drop: The switch enables configurable add/drop functionalities in optical setups, providing flexibility in network configurations.
Instrumentation: Its high stability and low insertion loss make it suitable for use in precision optical instrumentation systems, ensuring accurate measurements.
GEZHI's 1x4T Optical Switches are built to withstand the demands of continuous operation. With a durability of over 10 million cycles, these switches offer consistent and reliable performance over an extended period.
The 1x4T Optical Switch operates effectively in a wide range of conditions:
Operating Voltage: Choose between 3V or 5V DC voltage options, depending on your system requirements.
Operating Temperature: The switch remains stable in temperatures ranging from -5°C to +70°C, making it suitable for various environments.
Storage Temperature: With a storage temperature range of -40°C to +85°C, the switch is well-suited for long-term storage and harsh conditions.
GEZHI's 1x4T Optical Switch is a reliable and high-performance solution for optical multiplexers, cross-connect, and network switching applications. With its low insertion loss, high stability, and seamless switching capabilities, this optical switch ensures efficient and dependable signal routing. Whether you need to block channels, monitor systems, or configure add/drop functions, the 1x4T Optical Switch is a versatile component for your optical setups. Experience the reliability and precision of GEZHI's 1x4T Optical Switch for your network switching needs today!
